FreeWave

THE LEGEND THAT INVENTED AN ENTIRE BOARD CATEGORY!

Variant:

Unicolor (FreeWave)

FreeWave SLS - Unicolor
FreeWave SLS - Unicolor (FreeWave)
Item-no. 14240-1006

THE LEGEND THAT INVENTED AN ENTIRE BOARD CATEGORY! THE FIRST FreeWave IN 2004 PAVED THE WAY FOR A WHOLE NEW BOARD CATEGORY AND 20 YEARS LATER IS STILL LEADING THE WAY.

An evolution of the Stubby outline blended with our legendary FreeWave DNA, the FreeWave is a true chameleon – ready to adapt and excel in all conditions. From flatwater blasting, to jump n’ ride or moderate waves, the FreeWave covers the broadest range of use and conditions of our entire line-up.

In addition to the excellent wave characteristics, the FreeWave is also well suited for classic freestyle manoeuvres due to its flat deck and compact outline. The multiple footstrap inserts and fin options allow you to adjust the FreeWave according to your needs - so even on flat water you can leave your buddies in your wake!


The FreeWave comes in 6 sizes of 75, 85, 95, 105, 115 and 125l for heavier riders and lighter winds


Available in 2 constructions:

+ Wood Sandwich Technology: no one offers a better price - weight - durability ratio.

+ Premium Sandwich Technology - STRONG-LIGHT-SUPERIOR

Broadest Range
The FreeWave covers the broadest range of use and conditions of our entire Freestyle-Wave line-up
Multi footstrap inserts and fin options
The multi footstrap inserts and fin options allow you to adjust the FreeWave according to your needs
2 Technologies
Available in PREMIUM SANDWICH TECHNOLOGY (SLS) or WOOD SANDWICH TECHNOLOGY
FreeWave SLS - Unicolor (FreeWave)
Slower Waves
SNAPPY TURNS
Fast Waves
MAX. GRIP
Range Of Use
ACCELERATION & JUMPING
Range Of Use
KEEP SPEED DOWN THE LINE
Surfing Style
BACK FOOT SLASHES
Surfing Style
FRONT FOOT CARVING
Freestyle Ability
NEW SCHOOL
Freestyle Ability
CLASSIC
BOARD
VOLUME (L)
WIDTH (CM)
LENGTH (CM)
TECHNOLOGY FreeWave SLS
WEIGHT (KG) (+/-5%)
TECHNOLOGY FreeWave
WEIGHT (KG) (+/-5%)
FITTINGS FreeWave SLS
FITTINGS FreeWave
MAX. SAIL SIZE (M²)
BEST MATCHING ION BOARDBAG*
Best Size
FreeWave SLS 75
75
56
228
PREMIUM SANDWICH
5.80
--
--
FINS: 2 X TRI MFC SIDE (SLOT) 12 + 1 X TRI MFC CENTER (POWER) 18 | 3 X PREMIUM STRAP
--
5.8
Windsurf Core 230x58
Best Size
FreeWave SLS / FreeWave 85
85
58.5
229
PREMIUM SANDWICH
6.10
WOOD SANDWICH
6.70
FINS: 2 X TRI MFC SIDE (SLOT) 12 + 1 X TRI MFC CENTER (POWER) 19 | 3 X PREMIUM STRAP
FIN: 1 X F_WAVE (POWER) 26 | 3 X PREMIUM STRAP
6.0
Windsurf Core 235x61
Best Size
FreeWave SLS / FreeWave 95
95
61
230
PREMIUM SANDWICH
6.60
WOOD SANDWICH
6.90
FINS: 2 X TRI MFC SIDE (SLOT) 12 + 1 X TRI MFC CENTER (POWER) 20 | 3 X PREMIUM STRAP
FIN: 1 X F_WAVE (POWER) 28 | 3 X PREMIUM STRAP
6.2
Windsurf Core 235x61
Best Size
FreeWave SLS / FreeWave 105
105
63
231
PREMIUM SANDWICH
6.80
WOOD SANDWICH
7.20
FINS: 2 X TRI MFC SIDE (SLOT) 12 + 1 X TRI MFC CENTER (POWER) 21 | 4 X PREMIUM STRAP
FIN: 1 X F_WAVE (POWER) 30 | 4 X PREMIUM STRAP
6.7
Windsurf Core 240x66,5
Best Size
FreeWave SLS / FreeWave 115
115
65
232
PREMIUM SANDWICH
7.00
WOOD SANDWICH
7.50
FIN: 1 X F_WAVE (POWER) 32 + 2 X SLOT BOX - NO FIN | 4 X PREMIUM STRAP
FIN: 1 X F_WAVE (POWER) 32 | 4 X PREMIUM STRAP
7.3
Windsurf Core 240x66,5
Best Size
FreeWave SLS / FreeWave 125
125
68
234
PREMIUM SANDWICH
7.40
WOOD SANDWICH
7.95
FIN: 1 X F_RIDE 34 + 2 X SLOT BOX - NO FIN | 4 X PREMIUM STRAP
FIN: 1 X F_RIDE (POWER) 34 | 4 X PREMIUM STRAP
7.5
Windsurf Core Stubby 235x70

Main color specs when repairing the board

FreeWave SLS: Top: Pantone 3155 C | Bottom: Pantone 112 C

FreeWave: Top: Pantone 112 C | Bottom: Pantone Yellow C

default
TechFeature

WOOD SANDWICH TECHNOLOGY

The WOOD SANDWICH TECHNOLOGY consists of 40 individual parts and components and offers the best weight/durability vs. price ratio. This is achieved through combining the usual high density PVC sandwich foam with large wood reinforcement patches. This reduces the complexity of the layup which helps us to keep the price under control. Yet it leads to a very strong and just slightly heavier board compared to our Premium Sandwich Technology. We think there is no better performance for value construction out there.

PREMIUM SANDWICH TECHNOLOGY

The PREMIUM SANDWICH TECHNOLOGY consists of 50 individual parts and components and is our lightest semi custom technology. Achieved through lighter raw materials and a higher carbon content and a sophisticated layup with a much higher amount of load spot specific patches, stringers and reinforcements. Important these weight savings do not go to cost of durability. This is why as the first production brand we offer a 1 YEAR UNLIMITED WARRANTY on these boards when registered online (dents excluded).

Outline

Parallel outline design provides low drag and boosts control. The wide tail ensures incredible early planing and upwind performance and improves the take off for jumping.

Rail Shape

Medium rail diameter in the nose and center offer an ideal blend of performance and manoeuvrability. Thinned out rails towards the tail for maximum grip and control.

Deck Shape

Reduced dome deck shape results in a more stable/balanced stance, especially in drift & ride conditions.

Bottom Shape

Very smooth and comfortable ride especially in chop thanks to constant V bottom shape with slight double concaves.

Rocker Line

Faster rocker line boosts planing power especially on the larger sizes.

Mini Side Slot Boxes

The mini side slot boxes no longer offer any adjustment to prevent misplacing your fins. Now all adjustability for different riding styles and sail sizes is done through the center fin(s) only - Plug & Play and lighter weight!

Mini Mast-Track

The mini mast-track reduces the weight in the critical nose area. It also reduces the risk to misplace your mast base while still providing just the right amount of length adjustment for all riding styles and sail sizes.

Duotone Premium Strap

High quality closed cell neoprene for maximum longevity. Only black Lycra coating guarantees maximum comfort as well as maximum durability. The strap features measurement markings to allow you to quickly set up and replicate your individual size. Board specific attachments:

  • All World Cup boards come equipped with double-screw plugs to prevent any twist and ensuring the most direct connection to the board
  • All other boards come equipped with single-screw plugs to allow a faster repositioning of the straps plus a more comfortable ride due to a certain "give"


Duotone Pro Pads

8-10mm thick duo density EVA (depending on the board type) provides best dampening comfort and control. The heat pressed diamond grooving pattern protects the EVA against abrasion and provides an extraordinary grip level. We only select EVA colours which don't look dirty after use and will also resist fading after hours in the sun.

Fin Configuration

  1. All FreeWave sizes come with a Powerbox single fin - reduced weight and maximum Plug & Play.
  2. FreeWave SLS 75 to 105 come with a thruster setup offering even more grip during manoeuvres and turns (get delivered with 1 Powerbox center fin plus 2 Slotbox side fins).
  3. FreeWave SLS 115 and 125 come with a Powerbox single fin. The 2 additional side Slotboxes offer the option to switch to a thruster setup.


WOOD SANDWICH TECHNOLOGY

The WOOD SANDWICH TECHNOLOGY consists of 40 individual parts and components and offers the best weight/durability vs. price ratio. This is achieved through combining the usual high density PVC sandwich foam with large wood reinforcement patches. This reduces the complexity of the layup which helps us to keep the price under control. Yet it leads to a very strong and just slightly heavier board compared to our Premium Sandwich Technology. We think there is no better performance for value construction out there.

PREMIUM SANDWICH TECHNOLOGY

The PREMIUM SANDWICH TECHNOLOGY consists of 50 individual parts and components and is our lightest semi custom technology. Achieved through lighter raw materials and a higher carbon content and a sophisticated layup with a much higher amount of load spot specific patches, stringers and reinforcements. Important these weight savings do not go to cost of durability. This is why as the first production brand we offer a 1 YEAR UNLIMITED WARRANTY on these boards when registered online (dents excluded).

WOOD SANDWICH TECHNOLOGY

The WOOD SANDWICH TECHNOLOGY consists of 40 individual parts and components and offers the best weight/durability vs. price ratio. This is achieved through combining the usual high density PVC sandwich foam with large wood reinforcement patches. This reduces the complexity of the layup which helps us to keep the price under control. Yet it leads to a very strong and just slightly heavier board compared to our Premium Sandwich Technology. We think there is no better performance for value construction out there.

PREMIUM SANDWICH TECHNOLOGY

The PREMIUM SANDWICH TECHNOLOGY consists of 50 individual parts and components and is our lightest semi custom technology. Achieved through lighter raw materials and a higher carbon content and a sophisticated layup with a much higher amount of load spot specific patches, stringers and reinforcements. Important these weight savings do not go to cost of durability. This is why as the first production brand we offer a 1 YEAR UNLIMITED WARRANTY on these boards when registered online (dents excluded).

Outline

Parallel outline design provides low drag and boosts control. The wide tail ensures incredible early planing and upwind performance and improves the take off for jumping.

Rail Shape

Medium rail diameter in the nose and center offer an ideal blend of performance and manoeuvrability. Thinned out rails towards the tail for maximum grip and control.

Deck Shape

Reduced dome deck shape results in a more stable/balanced stance, especially in drift & ride conditions.

Bottom Shape

Very smooth and comfortable ride especially in chop thanks to constant V bottom shape with slight double concaves.

Rocker Line

Faster rocker line boosts planing power especially on the larger sizes.

Mini Side Slot Boxes

The mini side slot boxes no longer offer any adjustment to prevent misplacing your fins. Now all adjustability for different riding styles and sail sizes is done through the center fin(s) only - Plug & Play and lighter weight!

Mini Mast-Track

The mini mast-track reduces the weight in the critical nose area. It also reduces the risk to misplace your mast base while still providing just the right amount of length adjustment for all riding styles and sail sizes.

Duotone Premium Strap

High quality closed cell neoprene for maximum longevity. Only black Lycra coating guarantees maximum comfort as well as maximum durability. The strap features measurement markings to allow you to quickly set up and replicate your individual size. Board specific attachments:

  • All World Cup boards come equipped with double-screw plugs to prevent any twist and ensuring the most direct connection to the board
  • All other boards come equipped with single-screw plugs to allow a faster repositioning of the straps plus a more comfortable ride due to a certain "give"


Duotone Pro Pads

8-10mm thick duo density EVA (depending on the board type) provides best dampening comfort and control. The heat pressed diamond grooving pattern protects the EVA against abrasion and provides an extraordinary grip level. We only select EVA colours which don't look dirty after use and will also resist fading after hours in the sun.

Fin Configuration

  1. All FreeWave sizes come with a Powerbox single fin - reduced weight and maximum Plug & Play.
  2. FreeWave SLS 75 to 105 come with a thruster setup offering even more grip during manoeuvres and turns (get delivered with 1 Powerbox center fin plus 2 Slotbox side fins).
  3. FreeWave SLS 115 and 125 come with a Powerbox single fin. The 2 additional side Slotboxes offer the option to switch to a thruster setup.


WOOD SANDWICH TECHNOLOGY

The WOOD SANDWICH TECHNOLOGY consists of 40 individual parts and components and offers the best weight/durability vs. price ratio. This is achieved through combining the usual high density PVC sandwich foam with large wood reinforcement patches. This reduces the complexity of the layup which helps us to keep the price under control. Yet it leads to a very strong and just slightly heavier board compared to our Premium Sandwich Technology. We think there is no better performance for value construction out there.

PREMIUM SANDWICH TECHNOLOGY

The PREMIUM SANDWICH TECHNOLOGY consists of 50 individual parts and components and is our lightest semi custom technology. Achieved through lighter raw materials and a higher carbon content and a sophisticated layup with a much higher amount of load spot specific patches, stringers and reinforcements. Important these weight savings do not go to cost of durability. This is why as the first production brand we offer a 1 YEAR UNLIMITED WARRANTY on these boards when registered online (dents excluded).

TechFeature

3D View

YOUR PERFECT SAIL MATCH

Quote Arthur Arutkin - International Team

»THE FREEWAVE IS PURE FUN IN ANY TYPE OF CONDITIONS«

— Arthur Arutkin - International Team
Quote Daniel Aeberli - Product Manager Boards

»READY TO ADAPT AND PERFORM IN ALL CONDITIONS«

— Daniel Aeberli - Product Manager Boards
